HZH-260 series of all hydraulic highway piling machine is our company according to the needs of the road rail pile driving market, specially designed a new type of full hydraulic highway. The highway pile driver has the advantages of compact structure, can satisfy the requirements of multiple piling, wide working range, low energy consumption, high piling efficiency, comfortable operation, portability and flexibility, and low operating cost. HZH-260 series of highway piling machine based on hydraulic system, in the chassis mounted on the road system, the use of hydraulic motor drive for the construction site. By using hydraulic pressure to fight the piling method, the work efficiency is increased exponentially.
Characteristics of HZH-260 series hydraulic pile driving machine
The mature development of hydraulic system based on direct driving positioning. Flexible and efficient operation.
The full power control system makes full use of engine power, energy saving and high efficiency.
The best use of domestic diesel engine, ensure reliable power is strong.
The key hydraulic components are famous brand products, stable and reliable.
Full hydraulic drilling machine:
Without the power of the diesel engine (KW) 32
Hydraulic system flow (L/Min) 80-110
Rated system pressure (Mpa) 15
Track 1620 (M)
Wheelbase (M) 2070
Overall size (L * w * h)
Weight (Kg) of about 1900
Hydraulic hammer weight of piling device ((Kg) 180)
Hydraulic hammer striking frequency (Bpm) 500-900
Hydraulic hammer working flow (L/min) 40-70
Hydraulic hammer working pressure (Mpa) 11-14
Drilling unit power head weight (Kg) 140
The hole diameter (Mm) Phi Phi 200 120
Drilling speed (Mm/Min) 800 - 2000
Shock frequency (Bpm) 900-1200
Working pressure (Mpa) of the impact device 0.6-1.2
Impact device consumption (m3/min) 7-13
